Downlight with LED module for surface mounting 13W, which corresponds to 1x18W PL-C compact fluorescent lamp, 3000K, 1000 lumens, 50,000 hours.
CoreLine series
Downlight / Spot / Headlights
Outer diameter 169 mm
Protection class II
Reflector None
Lamp holder / base None
Leader area 4 mm²
Connection type Screw clamp
Color enclosure / frame White
Surface protection Powder coated
Voltage type AC
With motion sensor No.
Suitable for lamp power 13 W
Drive LED drive constant current
Color Interpretation Index (CRI / Ra) 80-89
Installation width 150 mm
Installation diameter 150 mm
With light sensor No.
Suitable for pendulum suspension No.
Lamp efficiency 80 lm / W
Brightness 376 cd
Number of poles 2
Height / depth 50 mm
Material enclosure / frame Aluminum
Light source LED non-replaceable
Light socket Direct
Material kupa Plast, opal
Light distribution Symmetrical
Impact resistance (IK) IK02
Rated voltage from / to 220 to 240 V
Enclosure class (IP) IP20
With light source Yes
Fire protection "D" No.
Suitable for number of light sources 1
Suitable for wall mounting Yes
Suitable for installation / recessing No.
Drives included Yes
Adapted for screen work No.
Suitable for surface mounting Yes
Spreading angle Open beam
Connectable conductor diameters 0.75 to 2.5 mm²
Color temperature 3000 K
System power 13.5 W
Nominal luminous flux according to IEC 62722-2-1 1100 lm
Adjustability Not adjustable
Suitable for pillars / floor mounting No.
Suitable for cable mounting Yes
Light color White
Suitable for rail mounting No.
Light flux 990 to 1210 ch
Type of cabling Completed
Energy Consumption Index for Energy Supply (EEI) A1
Nominal life L90 / B50 at 25 ° C 18000 h
Color fastness (McAdam ellipse) SDCM5
Distortion (THD) 0.134
Photobiological safety according to EN 62471 RG1
Filament test according to IEC 60695-2-11 650 ° C - 30 s
Nominal ambient temperature according to IEC62722-2-1 0 to 35 ° C
LED rated current at constant current 350 mA
Dimmer function missing Yes
Light output 80 lm / W
Light distributor / diffuser Diffuser lens / optics / panel
Suitable for ceiling mounting Yes
Installation height / depth 50 mm
Power factor 0.9
